Modification time!

[electra225]

It sure looks nice.

[TC Chris]

OK, for the unenlightened, more details please? Water-slide decals? Protective covering over them? Where do you buy the printable sheets?

Long ago I repaired a Zenith radio with one of those brass-finished steel rings for a tuning dial with the frequencies marked off on it. it was rusted beyond simple cleanup, so I spray-painted it gold, applied press-on numbers, and sprayed over that with clear finish. It worked well and looks good, but it was far less elegant than your job.

Chris Campbell

[hermitcrab]

You can buy blank water slide decal paper at hobby lobby, in the model car dept , also the dullcoat spray to seal in the decals by Testor's paint... but that paper is only for ink-jet printers , if you have a laser jet then there is paper for those, but I could not find it locally so I got some from amazon... then find the font on your computer or the internet that best matches your particular job...I think I used "Segoe UI" font on windows. it was the best match for the "a" in the Magnavox word... every "a" today looks like a @ sign . here is the sheet printed out with all the words before cutting them out ...

[William]

Great job, Elton, I would not have thought about any of what you just did.

Bill

[TC Chris]

Me neither. Thanks for sharing so the rest of us can give it a try.

Chris Campbell

[hermitcrab]

Guess I am not done modifying... the R2R needs to be matched to the system , can only get decent room volume turning the master volume all the way up , I see the AUX input only has a 220K resistor in line according to the schematic , later sets use 100K and a bypass cap ...anything I plug into the Aux is low output... maybe the standards were different back in 64 ? The only thing I can figure is a impedance mismatch ....

[electra225]

Are you certain the electronics in the R2R are up to snuff? Do you have another line-level source you can try to see if the issue is in the console or in the R2R? I have never owned a solid state Magnavox, but I've not had issues feeding tape decks and CD changers into the tape input of a tube instrument.

[hermitcrab]

User error!.... plugging in the RCA's into the magnavox aux jacks ,and some bad vision, I plugged the input and outputs backwards ... the letter stamping on the chassis did not help either... it's playing good

[hermitcrab]

OK.... Finished product... I shall not speak of this again

[TC Chris]

Speak of it all you want; it was a cool project, well done. Pat yourself on the back for the accomplishment. Wish we could al hear it performing!

Chris Campbell

[hermitcrab]

Here is a quick video of it playing....https://www.youtube.com/watch?v=tDMwz0EAJvw

[walyfd]

Now that's a console! Great job and you didn't think you were going to keep it.

[William]

Great job, Elton, and even with my crummy computer speakers I can tell it has plenty of bass.

Bill

[hermitcrab]

Now that's a console! Great job and you didn't think you were going to keep it.

Yea... I know .... but fortunately I sold 3 consoles before Christmas this year...which gave me the room to keep it...

[William]

There's always room for one more!
